(10) Draw a ray diagram for a 3.0-cm tall object placed 10.0 cm from a converging lens having a focal length of 15.0 cm. (11) Draw a ray diagram for a diverging lens that has a focal length of -10.8 cm when an object is placed 32.4 cm from the lens's surface. (12) Draw a ray diagram for an object placed 6.0 cm from the surface of a converging lens with a focal length Draw a ray diagram and use the information from the ray diagram to fill in the box. 5b) Explain why no image can be formed when the object is placed at the focal point. 6a) A 15.0 cm object is placed 10.0 cm from a convex lens, which has a focal length of 15.0 cm. Draw a ray diagram and use the information from the ray diagram to fill in the box.

Chapter 22 Ray Diagrams Practice Worksheet A ray diagram helps you see where the image produced by a lens appears. The components of the diagram include the lens, the principal axis, the focal point, the object, and three lines drawn from the tip of the object and through the lens. These light rays meet at a point and intersect on the other ...

Converging lens ray diagram worksheet

Worksheet 11-Lenses Formulas and Concepts Snell’s Law: ... lens for converging and in front of the lens for diverging. 1. Draw a ray diagram to determine the location of the image formed by the object shown using the concave mirror below. 2. Draw a ray diagram to determine the location of the image formed by the object shown using View L10- Worksheet Key.pdf from SC CSE 1020 at York University. Lesson 10- Worksheet Answer Key Lens Ray Diagrams and Calculations Worksheet - Solutions 1. Diverging lens: di = -4.16 cm hi = 0.83 Diverging Lenses As such, the rules for how light behaves when going through a diverging lens is a little bit different. You will be expected to be able to draw a Ray Diagram of a converging and diverging lens on our upcoming test without the rules.

Converging lens ray diagram worksheet. Converging Lens (focal lengths greater than zero) 1. Draw a ray from (top of) object through center of lens. 2. Draw a ray from (top of) object parallel to axis. When the ray reaches the lens plane it bends so that the ray passes through the focal point (A). 3. Draw axial ray through lens. (The dotted line already shown) 4. The Physics Classroom » Curriculum Corner » Refraction and Lenses » Ray Diagrams for Converging Lenses. The document shown below can be downloaded and printed. Teachers are granted permission to use them freely with their students and to use it as part of their curriculum. Visit the Usage Policy page for additional information. Ray Diagrams By constructing a ray diagram, we can determine where the image is located, and what it will look like. A ray diagram is a diagram showing rays that can be drawn to determine the size and location of an image formed by a mirror or lens. Ray Diagram for Object Located in Front of the Focal Point. In the three cases described above - the case of the object being located beyond 2F, the case of the object being located at 2F, and the case of the object being located between 2F and F - light rays are converging to a point after refracting through the lens. In such cases, a real image is formed.

Diverging Lenses As such, the rules for how light behaves when going through a diverging lens is a little bit different. You will be expected to be able to draw a Ray Diagram of a converging and diverging lens on our upcoming test without the rules. View L10- Worksheet Key.pdf from SC CSE 1020 at York University. Lesson 10- Worksheet Answer Key Lens Ray Diagrams and Calculations Worksheet - Solutions 1. Diverging lens: di = -4.16 cm hi = 0.83 Worksheet 11-Lenses Formulas and Concepts Snell’s Law: ... lens for converging and in front of the lens for diverging. 1. Draw a ray diagram to determine the location of the image formed by the object shown using the concave mirror below. 2. Draw a ray diagram to determine the location of the image formed by the object shown using
